The Zen TORII Monos

Model TORIIMONO

DESIGNED FOR THE KT88 TUBE

an anniversary grade 60 watt masterpiece from Decware
$12,500 factory wholesale for a pair

Liberating serious audiophiles from the buy and sell marry-go-round!

The Zen TORII Mono's represent Decware's highest power flagship amplifiers at 60 watts per channel. They maintain the transparency and prat of our lower power amplifiers bringing the Decware sound to less sensitive audiophile loudspeakers.

They are KT-88 based class A push-pull amplifiers built in the Zen tradition with no circuit boards and precious few parts in the signal path. Each amplifier is upgraded to our full anniversary standard.

FEATURES

Easy-to-use, real-time manual tube bias with meters and adjustment knobs.
Massive high voltage power supply caps.
Transformer-coupled XLR inputs.
Point-to-point wired with no circuit boards.
Volume control on each amplifier.
Solid hardwood base.
6922 based dual-tube driver-stage.
Powder-coated black typewriter finish.
Operates without excessive heat.

TUBE BIASING

With this amplifier it is possible to explore many different brands of KT88 tubes without the stress of worrying if they exactly match or not. * This is because there is a balance control between the meters that allows you to match the tubes to each other even with music playing.

*In a push-pull amplifier if the output tubes don't match you will develop hum.

MASSIVE HIGH VOLTAGE CAPS

The black cans behind the KT88 output tubes are combined to create a 1000VDC ultra high microfarad power supply that yields amazing dynamic headroom but also incredibly black backgrounds. This was done because we live in a world with dirty power at the wall outlets and not everyone can afford or wants a giant noisy power regenerator to clean the power - so we make the amplifier do it. Since the amplifier has a working voltage below 500VDC the capacitors are double what they need to be for safety and longevity.

TRANSFORMER COUPLED INPUTS

The XLR inputs on these amplifiers are transformer-coupled using Sowter of England transformers for ultra-flat and ultra-wide bandwidth. The transformers have an effect on the sound that is very positive by adding dimensionality and tone. Similar to what a good moving coil cartridge does. It would have been easier and less expensive to just make the amplifiers differential balanced and not use one. (RCA input is also provided)

POINT TO POINT WIRING

The complete absence of circuit boards puts everything in 3D space where the fields of wires and parts can be controlled. Everything is better, it sounds superior and doesn't break.

VOLUME CONTROL

Each amplifier has one. You can think of it as an input sensitivity or gain control. But it makes it possible to run the amp without a preamp and sometimes that will sound better. Also it makes it much safer to use as you can rotate the volume off whenever the amp is not in use so that turning it on with a signal blaring from your source doesn't scare the crap out of you.

SOLID HARDWOOD BASE

We makes these amps from 1/8 inch cold rolled steel that is high in mass and we direct-couple that to a solid hardwood base to create a resonate free amplifier which improves the sound. These bases are available in different woods and styles.

6922 BASED DRIVER STAGE

The driver aka input stage is based on the popular 6922 dual triode and is direct-coupled to a second 6922 used as a phase inverter. We ship these amplifiers with a wonderful sounding Russian military version of this tube called a 6N1P-EV.

POWDER COAT FINISH

The only finish that won't scratch off over time as it is electrostatically applied as a powder and then baked into the metal at high temperature.

OPERATES WITHOUT EXCESSIVE HEAT

This is because the power supply is oversized so that it does not run hot, and because there are only four tubes.

DESIGNED FOR EXTREME FIDELITY

GALLERY

OPTIONS

The following options are selectable from within the shopping cart.

Tubes

This amplifier is available with some different options regarding tubes.

1) The amp can be purchased without tubes at a significant savings.

2) The amp can be purchased with Steve's (hand picked and calibrated in the actual amplifier) favorite tube complement using budget 300B tubes and a coupon for 10% off Western Electric WE300B tubes that can be used when you're ready to upgrade.

3) The amp can be purchased with Steve's (hand picked and calibrated in the actual amplifier) favorite tube complement without 300B tubes and a coupon for 10% off Western Electric WE300B tubes.

Knobs

From left to right is; Ebony, Gold, Black Chicken Head, Cream Chicken Head, Rosewood

Anniversary Mods -

This amplifier comes with full Anniversary Mods which include Foil bypass caps in the power supply and F&T mains caps. These mods are included at no extra charge.

XLR Inputs -

If you want to run balanced XLR into this amp, use our product called the ZBIT. You would set the ZBIT next to the amplifier and adjust it's output to your liking. It can be used like a master volume for both channels which is handy since the amp has dual volume controls.

Voltage -

The amp has a CE rated world voltage compatible power transformer. You can select your voltage from within the shopping cart. A power cord for your country will be supplied with the amplifier.

Available Woods

Walnut

Maple

Cherry

Oak

Padauk

Sapele

The Sarah model SEWE300B amplifier has its own unique 1.5 inch thick solid hardwood base design because it is too thick to fit into standard Decware bases. It comes in your choice of the above woods. Custom wood bases may be available for quote and would be non-refundable and paid for in advance.

SPECIFICATIONS

World Voltage compatibility 50/60Hz
DRIVER TUBE Compatibility: 6N6P, 6922, 6N1P
INPUT TUBE Compatibility: 12AU7
OUTPUT TUBE Compatibility: WE300B
VOLTAGE REGULATOR TUBE Compatibility: OC2, OA2 OB2
RECTIFICATION: 274B or 5U4 or 5AR4
INPUTS: Two pair isolated 24K Gold RCA INPUTS with switching.
OUTPUTS: LO & HI , for 2~6 & 8~16 OHM SPEAKERS
IDLE CURRENT: 65~75 MILS PER OUTPUT TUBE
HIGH VOLTAGE: 390 VDC AT TRANSFORMERS
INPUT IMPEDANCE: 100 K OHMS
INPUT SENSITIVITY: FULL POWER @ 2.0 VOLTS
POWER INTO 8 OHMS: 4 to 7 WATTS PER CHANNEL @ 3%THD PENDING VR TUBE USED
NOISE: -80dB
CURRENT METERS: 0 to 100 MA
SIGNAL CAPACITORS: COPPER FOIL MIFLEX
ELECTROLYTIC CAPACITORS: F&T
BYPASS CAPACITORS: COPPER FOIL MIFLEX
CATHODE CAPS: NICHICON MUSE, ATOM
INPUT JACKS: MACHINED GOLD RCA
OUTPUT JACKS: RED COPPER BINDING POSTS
MACHINED STEEL CHASSIS with POWDER COAT FINISH
IEC CONNECTOR: HOSPITAL GRADE DUAL FUSED / NOISE FILTER
SWITCHING: DUAL CONTACT SILVER
SOCKETS: EIZZ Gold Ceramic
SIZE: 17-1/4" WIDE x 13-3/4" DEEP x 9-3/4" HIGH
NET WEIGHT: 31 LBS.
CAN BE BRIDGED INTO EITHER SINGLE-ENDED or DIFFERENTIAL BALANCED MONOBLOCKS
WARRANTY: LIFETIME TO ORIGINAL OWNER

MANUALS

Screen Shot 2022-12-13 at 8.04.25 PM.png

Amp Manual in .pdf format

Screen Shot 2022-12-12 at 4.13.14 PM.png

Tube Manual in .pdf format

SUPPORT

Since we don't have dealer's and we sell our amplifiers directly to the customer, our customers have a direct line to us. As a result, Decware support is legendary for 25 years.

Support is not only a phone call or email away at any time, but when you purchase this amplifier you join a huge family of customers who also own one and enjoy supporting each other on our support forums.

DECWARE Support Forums

TRY THIS AMP AT HOME FOR 30 DAYS!

Return IT if not satisfied FOR 10% RESTOCK FEE !

MODEL TORIIMONO

60 WATTS x 2

$12500 with tubes

No product

Amps are hand-built to order. There are presently lots of orders on our real time build sheet. A 10% deposit secures your place on the list with today's date and time stamp. Balance is due when it's ready to ship. We will send you a final invoice with the total price including actual shipping costs shortly after your deposit is taken.
